Glove Box Scroll Nqus Pump
Qauv: SPL-20
Lub cev muaj zog: 0.75 KW
Pump ceev: 20 m³ / h
- Khoom Taw qhia
Cov ntaub ntawv khoom
Lub hnab looj tes scroll lub tshuab nqus tsev twj yog ib hom tshiab ntawm lub tshuab nqus tsev twj tso kua mis, uas yog hloov zuj zus los ntawm scroll compressor. Nws muaj me me clearance, me me to, siab compression piv thiab ruaj khov ceev ceev nyob rau hauv ib tug dav ua hauj lwm siab ntau yam. Nws qhov kev ua haujlwm siab ntau yog dav. Vim tias qhov ntim ntawm lub compression chamber hloov tsis tu ncua, lub zog tsav tsheb thiab lub zog hloov pauv me me.
Lub hnab looj tes scroll lub tshuab nqus tsev twj tso kua mis muaj cov qauv yooj yim thiab ob peb qhov chaw, yog li nws ua haujlwm ruaj khov, tsis tshua muaj kev vibration, tsis tshua muaj suab nrov thiab muaj kev ntseeg siab. Nws txais yuav vortex profile thiab yog optimized los ntawm qhov seem mus rau seem sib txawv, uas zoo heev txhim khu lub peev xwm ntawm cov roj extraction. Lub tshuab nqus tsev twj tso kua mis no tuaj yeem pib ntawm atmospheric siab (10 ^ 5Pa) thiab tuaj yeem tawm ncaj qha mus rau hauv qhov chaw ua haujlwm ntawm nws tus kheej. Nws cov khoom tseem ceeb yog ua los ntawm cov khoom siv polymer sib xyaw, uas tuaj yeem tshem tawm cov roj corrosive.
Cov ntsiab lus ceev:
Qhov chaw keeb kwm: Zhejiang, Suav teb (Mainland)
Brand Name: TSVP
Xim: xaiv tau
Ntim Cov Lus Qhia: Carton lossis Pallet
Chaw nres nkoj: Ningbo
Daim ntawv thov
Daim ntawv thov ntau yam ntawm cov hnab looj tes scroll lub tshuab nqus tsev twj tso kua mis tau nthuav dav rau cov roj thiab tshuaj lom neeg kev lag luam, roj thiab roj rov qab, kev tshawb fawb engineering thiab lwm yam dav. Lub twj tso kua mis yog siv dav hauv Kev Lag Luam, Semiconductor, Zog thiab Tshuaj, Khoom Noj thiab Tshuaj, Kev Tshawb Fawb thiab Kev Tshawb Fawb, Kev Tshawb Fawb Kev Tshawb Fawb, thiab lwm yam, thiab nws feem ntau siv hauv cov khoom siv hauv qab no:
1) Nqus pob cia; 2) Lub tshuab nqus tsev vacuum; 3) Qhov cub / khov-qhuav; 4) Exhaust chaw nres tsheb; 5) Roj rov qab / rov ua dua tshiab; 6) Cov tub yees / cua txias yeeb nkab nqus tsev vacuum; 7) Nres / Kab nqus; 8) Laser nqus tsev vacuum; 9) Molecular twj tso kua mis ua ntej theem | 10) Cov txheej txheem ua ntej lub tshuab nqus tsev; 11) Nqus txheej zaj duab xis; 12) Kev kuaj pom dej; 13) Hnab looj tes; 14) Mass spectrometer; 15) Electron microscope; 16) High zog ceev kab / Accelerator; 17) Lub tshuab nqus tsev ntsuas siab; 18) Kev npaj ua qauv. |
Technical Data
Qauv | SPH10 | SPH15 | SPH 20 | SPL10 | SPL15 | SPL20 |
Pumping ceev (m3/h) | 10 m3/h (6.7cfm) | 15 m3/h (8.9cfm) | 20 m3/h (13cfm) | 10 m3/h (6.7cfm) | 15 m3/h (8.9cfm) | 20 m3/h (13cfm) |
Qhov kawg siab (mbar) | 2 pa/0.02mbar | 1 pa/0.01mbar | Tsawg dua los yog sib npaug rau 30 pa/0.3mbar | Tsawg dua lossis sib npaug li 20 pa/0.2mbar | ||
Rotary ceev (rpm) | 1800 rpm ib | 1500 rpm | ||||
Txuas | KF 25 | KF 25 | ||||
Fais fab mov (w) | 550W | 750W | 550W | 750W | ||
Rated zog (v) | 100-240V/50-60HZ | 100-240V/50-60HZ | ||||
Qhov Loj (mm) | 442 * 278 * 308 hli | 442 * 278 * 308 hli | ||||
Qhov hnyav (kg) | 25.2 kg ib | 25.6 kg ib | 25.8kg 2 | 25.2 kg ib | 25.6 kg ib | 25.8kg 2 |
Vapor Pumping peev xwm (g / h) | 145 | 220 | 160 | 250 | ||
Lub suab nrov (dbA) | 56db ua | |||||
Txoj kev txias | Cua txias | |||||
Ua haujlwm kub | 5-45 degree (41-113℉) | |||||
Daim ntawv thov
Ntim & Xa khoom:
Peb cov neeg muas zaub muaj ntau yam kev xaiv rau kev thauj mus los
Los ntawm Express (FedEx, UPS, DHL, TNT, EMS, thiab lwm yam ... )
--- Qhov zoo: ceev (yuav siv li ntawm 7 - 10 hnub hauv kev xa khoom), qhov rooj rau qhov rooj
--- Qhov tsis zoo: kim me ntsis
Los ntawm Kev Thauj Mus Los
--- Qhov zoo: ceev (yuav siv li ntawm 8 - 12 hnub), pheej yig dua li Express me ntsis.
--- Qhov tsis zoo: Koj yuav tsum nqa cov khoom ntawm tshav dav hlau los ntawm koj tus kheej.
Los ntawm Hiav Txwv (Hiav Txwv) Tsheb thauj mus los
--- Qhov zoo: Ntau qhov pheej yig dua li Express lossis Air tsheb thauj mus los.
---Qhov tsis zoo: qeeb thiab koj yuav tsum nqa cov khoom ntawm koj qhov chaw nres nkoj ntawm koj tus kheej.
Peb Qhov Kev Pabcuam
Kev Sib Tham Ua Ntej Muag
1.Pab xaiv tus qauv zoo
2.Muab luv nqi rau kev yuav khoom ntau
3.Prompt ntau lawm thiab xa khoom
Kev saib xyuas tom qab muag
1.12 hli warranty thiab lub neej txij nkawm
2.Free hloov rau qee qhov chaw
3. Kev npaj kho mob
FAQ
Q1: Puas yog siv kuv lub logo ntawm cov khoom?
A1: Yog lawm, thov qhia rau peb paub ua ntej peb tsim thiab paub meej tias tus qauv tsim ua ntej raws li peb cov qauv.
Yog tias koj muaj koj daim ntawv teev npe, thov xa tuaj rau peb.
Q2: Koj puas muab kev lees paub rau cov khoom?
A2: yog, peb muab 12 lub hlis lav rau peb cov khoom.
Q3: Kuv tuaj yeem paub ntau ntxiv txog koj cov khoom li cas?
A3: Txais tos nug peb!
Q4: Kuv tuaj yeem tau txais cov lus teb ntev npaum li cas tom qab peb xa cov lus nug?
A4: Peb yuav teb koj li ntawm 12 teev hauv hnub ua haujlwm.
Q5: Cov nqe lus them nqi yog dab tsi?
A5: TT nrog 30 feem pua ntawm cov nyiaj them poob haujlwm, 70 feem pua ntawm cov khoom xa tuaj lossis L / C thaum pom.
Paypal lossis West Union kuj lees txais.
